Back Pressure Regulator

Back pressure regulator is a wonderful device for relief pressure automatic in oil & gas service. it is actuated by the static upstream pressure, whcih causes the valve to open at set pressures, the degree of opening will vary and increase in proportion to the increase in pressure over the opening pressure. our back pressure regulator is same as WellMark back pressure regulator series W7702.

The CCSC Back Pressure Regulator is available in 2" size, which is suitable for pressure setting up to 1500 psi.

Back Pressure Regulator Application

● Paraffin
● Heading up
● By-pass to casing
● For LACT units to assure full-line operation and for safety relief on separators or casing.

Specifications

● Process Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 2" NPT
● Operating Pressure . . . . . . . . . . . . . . . . . . . . . . . 1500 psi Max.
● Pressure Setting Adjustment . . . . . . . . . . . . . . . . . . 5-1500 psi
● Operating Temperature . . . . . . . . . . . . . . . . . . . . -20°F to 300°F
